(Hong Kong)
Product Summary
KEY FEATURES
Up to 600MHz, 1.67 ns instruction cycle rate
24M bits of internal—on-chip—DRAM memory
25 mm × 25 mm (576-ball) thermally enhanced ball grid
array package
Dual-computation blocks—each containing an ALU, a
multiplier, a shifter, a register file, and a communications
logic unit (CLU)
Dual-integer ALUs, providing data addressing and pointer
manipulation
Integrated I/O includes 14-channel DMA controller, external
port, four link ports, SDRAM controller, programmable
flag pins, two timers, and timer expired pin for system
integration
1149.1 IEEE-compliant JTAG test access port for on-chip
emulation
Single-precision IEEE 32-bit and extended-precision 40-bit
floating-point data formats and 8-, 16-, 32-, and 64-bit
fixed-point data formats
Parametrics
KEY BENEFITS
Provides high performance static superscalar DSP
operations, optimized for telecommunications
infrastructure and other large, demanding multiprocessor
DSP applications
Performs exceptionally well on DSP algorithm and I/O
benchmarks (see benchmarks in Table 1)
Supports low overhead DMA transfers between internal
memory, external memory, memory-mapped peripherals,
link ports, host processors, and other
(multiprocessor) DSPs
Eases DSP programming through extremely flexible instruction
set and high-level-language-friendly DSP architecture
Enables scalable multiprocessing systems with low communications
overhead
Provides on-chip arbitration for glueless multiprocessing
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADSP-TS201SABPZ060 |
|
IC PROCESSOR 600MHZ 576BGA |
Data Sheet |
|
|
||||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||||
 |
ADSP-2100 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||||
 |
ADSP-2101BG-100 |
|
IC DSP CONTROLLER 16BIT 68PGA |
Data Sheet |
|
|
||||||||||||||
|
ADSP-2101BGZ-100 |
Analog Devices Inc |
IC DSP 16BIT CTRL 25MHZ 68-PGA |
Data Sheet |
Negotiable |
|
||||||||||||||
 |
ADSP-2101BP-100 |
|
IC DSP CONTROLLER 16BIT 68PLCC |
Data Sheet |
|
|
||||||||||||||
|
ADSP-2101BPZ-100 |
|
IC DSP SLG 16BIT 25MHZ 68-PLCC |
Data Sheet |
|
|
||||||||||||||
|
ADSP-2101BS-100 |
Analog Devices Inc |
IC DSP CONTROLLER 16BIT 80PQFP |
Data Sheet |
Negotiable |
|
||||||||||||||
